Kowa LM16JC10M

Kowa
|
SQ7468813
$794.00 $0.00( / )
Shipping calculated at checkout.

2/3" 16mm 10MP

Categories:
, ,

2/3" 16mm 10MP



The Kowa LM16JC10M features 200lp/mm resolution and low distortion in order to maximize performance for high-end applications.

Floating mechanism design virtually eliminates optical abberations from close distance to infinity

High precision aspherical lens greatly reduces distortion.

Incorporates wide-band coating and a floating mechanism design to maintain a high transmission from visible to NIR.

Easy installation in compact machine vision systems.

Vendor: Kowa Product Type: PHYSICAL SKU: SQ7468813 Weight: 1.0 lb

Ships in 1-3 days. Full manufacture warranty.

Authorized Kowa distributor.


  • Image Size 2/3" (8.8 x 6.6 x 11mm)

  • Iris Range (F-Stop) F1.8 - 16

  • Angle of View 1/2" (Hor. x Ver. x Dia.) 22.0 x 16.6 x 27.4°

  • Angle of View 1/1.8" (Hor. x Ver. x Dia.) 24.7 x 18.6 x 30.7°

  • Angle of View 2/3" (Hor. x Ver. x Dia.) 30.0 x 22.7 x 37.1°

  • TV Distortion -0.20%

  • Temperature Range -10°C ~ +50°C

  • Storage Temperature Range -20°C ~ +60°C

  • Resolution: Center/Corner Center 200lp/mm / Corner 140lp/mm

  • Weight 90g
