Fujifilm HF12.5SA-1 Lens
Fujifilm 5 Megapixel 2/3" Lens
Fujifilm 5 Megapixel 2/3" Lens
The Fujifilm minimizes distortion which causes problems in applications requiring high accuracy such as dimension measurement. This series is designed to achieve high resolution up to 5 megapixels (3.45µm pixel pitch) compatible with 2/3" sensors.
Focal length [mm] | 12.5 |
Iris range (F. no) | F1.4-F22 |
Angle of view | 38.0°x 29.0° (2/3") |
Working Distance*2 (mm) | ∞‐100 |
Operation of focus | Manual |
Operation of iris | Manual |
Filter thread [mm] | M49 x 0.75 |
Mount | C-mount |
Weight (approx.) [g] | 295 |
Sensor size (std.)*3 | 2/3" (3.45μm) |
Sensor size (max.)*4 | 2/3" (3.45μm) |
TV distortion [%] | -0.08 |
Dimension [mm] | Φ51×68.5 |
