Fujifilm DF6HA-1B

Fujifilm
|
DF6HA-1B
$132.00 $0.00( / )
Shipping calculated at checkout.

Fujinon DF6HA-1B 1.5 Megapixel 1/2" Lens, 6mm Focal Length

Categories:

Fujinon DF6HA-1B 1.5 Megapixel 1/2" Lens, 6mm Focal Length

FUJINON Anti-Vibration performance has passed vibration test conforming to IEC60068-2-6. This feature helps to keep both the mechanical and optical elements in their original position while maintaining superb resolution.



Focal length [mm]6
Iris range (F. no)F1.2-F16
Angle of view57.3°x 43.8° (1/2")
Working Distance*2 (mm)∞‐100
Operation of focusManual
Operation of irisManual
Filter thread [mm]M27 x 0.5
MountC-mount
Weight (approx.) [g]50
Sensor size (std.)*21/2" (4.5μm)
Sensor size (max.)*31/2" (4.5μm)
TV distortion [%]-1.84
Dimension [mm]

Φ29.5×36.7





Model
()old model name
Compatible format sizesFocal length
(mm)
4/31.111/1.22/31/1.81/21/3
DF6HA-1S
(DF6HA-1B)
6
HF9HA-1S
(HF9HA-1B)
9
HF12.5HA-1S
(HF12.5HA-1B)
12.5
HF16HA-1S
(HF16HA-1B)
16
HF25HA-1S
(HF25HA-1B)
25
HF35HA-1S
(HF35HA-1B)
35
HF50HA-1S
(HF50HA-1B)
50
HF75HA-1S
(HF75HA-1B)
75
