Fujifilm CF12.5HA-1Lens
Fujinon 1.5 Megapixel 1" Lens
Discontinued. Please inquire for recommended alternative options.
Fujinon 1.5 Megapixel 1" Lens
The Fujifilm CF series minimizes distortion which causes problems in applications requiring high accuracy such as dimension measurement, while the low F-number up to F1.4 ensures a clear image even in low light situations. This series is compatible with large 1" image sensor cameras to realize high resolution up to 1.5 megapixels (7.4 pixel pitch).
Focal length [mm] | 12.5 |
Iris range (F. no) | F1.4-F22 |
Angle of view | 53.1°x 41.2° (1") |
Working Distanc*2 (mm) | ∞‐100 |
Operation of focus | Manual |
Operation of iris | Manual |
Filter thread [mm] | M49 x 0.75 |
Mount | C-mount |
Weight (approx.) [g] | 290 |
Sensor size (std.)*3 | 1" (9.1μm) |
Sensor size (max.)*4 | 1" (9.1μm) |
TV distortion [%] | 0.86 |
Dimension [mm] | Φ51×68.5 |
